Premium +
Reusable Packaging
Duration
Up to 244 hours
ISTA 7D
Payload
From 1.5 L to 185 L
Temperature range
Deep freeze
| DEEP FREEZE VYPE | |||||
|---|---|---|---|---|---|
| Product name | Payload | Internal Space(1) L x W x H |
External dimension L x W x H |
Volumetric weight | System weight(2) |
| Deep Freeze VYPE 20 | 20 L | 272 x 272 x 276 mm 10.7 x 10.7 x 10.9 in |
390 x 375 x 360 mm 15.4 x 14.8 x 14.2 in |
9 kg 20 lb |
4.5 kg 9.9 lb |
| Deep Freeze VYPE 31 | 31 L | 312 x 312 x 316 mm 12.3 x 12.3 x 12.4 in |
430 x 415 x 400 mm 16.9 x 16.3 x 15.7 in |
12 kg 27 lb |
5.4 kg 12.0 lb |
| Deep Freeze VYPE 52 | 52 L | 372 x 372 x 376 mm 14.6 x 14.6 x 14.8 in |
490 x 475 x 460 mm 19.3 x 18.7 x 18.1 in |
18 kg 40 lb |
7.6 kg 16.8 lb |
| Deep Freeze VYPE 64 | 64 L | 372 x 372 x 466 mm 14.6 x 14.6 x 18.3 in |
490 x 475 x 550 mm 19.3 x 18.7 x 21.7 in |
22 kg 48 lb |
6.9 kg 15.2 lb |
| Deep Freeze VYPE 79 | 79 L | 460 x 460 x 375 mm 18.1 x 18.1 x 14.7 in |
580 x 575 x 460 mm 22.8 x 22.6 x 18.1 in |
27 kg 59 lb |
7.8 kg 17.2 lb |
| Deep Freeze VYPE 99 | 99 L | 462 x 462 x 466 mm 18.2 x 18.2 x 18.3 in |
580 x 575 x 550 mm 22.8 x 22.6 x 21.7 in |
31 kg 68 lb |
11.7 kg 25.8 lb |
| Deep Freeze VYPE 185 | 185 L | 702 x 482 x 548 mm 27.6 x 19.0 x 21.6 in |
800 x 600 x 648 mm 31.5 x 23.6 x 25.5 in |
52 kg 115 lb |
18.0 kg 39.7 lb |
(1)Space available for dry ice and payload (2)Weight without dry ice and payload
| DEEP FREEZE VYPE WITH PAYLOAD CONTAINMENT SYSTEM | |||||
|---|---|---|---|---|---|
| Product name | Payload | Internal Space(1) L x W x H |
External dimension L x W x H |
Volumetric weight | System weight(2) |
| Deep Freeze VYPE 20 | 1.5 L | 170 x 170 x 52 mm 6.7 x 6.7 x 2 in |
390 x 375 x 360 mm 15.4 x 14.8 x 14.2 in |
9 kg 20 lb |
4.5 kg 9.9 lb |
| Deep Freeze VYPE 31 | 2.9 L | 202 x 202 x 72 mm 8 x 8 x 2.8 in |
430 x 415 x 400 mm 16.9 x 16.3 x 15.7 in |
12 kg 27 lb |
5.4 kg 12.0 lb |
| Deep Freeze VYPE 52 | 9.1 L | 262 x 262 x 132 mm 10.3 x 10.3 x 5.2 in |
490 x 475 x 460 mm 19.3 x 18.7 x 18.1 in |
18 kg 40 lb |
7.6 kg 16.8 lb |
| Deep Freeze VYPE 99 | 21.4 L | 338 x 338 x 187 mm 10.3 x 10.3 x 5.2 in |
580 x 575 x 550 mm 22.8 x 22.6 x 21.7 in |
31 kg 68 lb |
11.7 kg 25.8 lb |
| Deep Freeze VYPE 185 | 47.4 L | 568 x 348 x 240 mm 22.4 x 13.7 x 9.5 in |
800 x 600 x 648 mm 31.5 x 23.6 x 25.5 in |
52 kg 115 lb |
18.0 kg 39.7 lb |
(1)Space available for dry ice and payload (2)Weight without dry ice and payload
EMBALL’ISO manages the collection of reusable packaging at your destination.
These packaging are returned using the transportation method with the lowest CO₂ emissions to the nearest EMBALL’ISO Service center. They are then cleaned, refurbished, and inspected by EMBALL’ISO to ensure the same performance. They can be reused within the same country or shipped back by sea freight to where customers need them.
